Halogen Line Heater Laboratory-kit LKHLH-35A/f∞/200v-1kw +HCVD

Easily heating high temperatures!

◆ Feature ◆

1. 1. Easily heating high temperatures by the kit!
   2. Easily heating high temperatures at free range!
   3. Easily adjusting the radiation area by manual lift!
   4. Easily changing the heat power (wattage) by Manual power controller!

1. It is so simple cooling system use cooling fan.

[ Power:10v-23w ]

Can be varied to AC0v – AC100v in large volume of manual variable power supply.
Variable of the electric power is carried out by voltage adjustment, and heating temperature can be adjusted.
It is a freely from low to high temperatures.

[ Power:100v-1000w ]

It shine so very bright emission of heat generation 1000W maximum output.
Hot surface heating can be simply performed in non-contact.

Example of lab kit assembly.

*The lab kit is delivered as individual components.

1. Cubic　test stand
2. Heater mounting bracket
3. Manual lift.
4. Brick
5. Safety glasses against high intensity light
   It can visually check the high-intensity irradiation point at maximum output.
6. Halogen Line Heater　HLH-35A/f∞/100v-1000w
   The output of 1kw, to heat the surface of the object.
7. Manual power controller HCVD-AC220V/AC200V-2KW
   By varying the AC220v to AC0 – 200v in volume, user can adjust the heating output.
   Equipped with DC24V power for air cooling fan.
